1Z2AZ2-K 300/500 V
This cable does not meet Art’s double insulation requirements. CEI 412.2.4.1 b) Conduit of the DC portion of the photovoltaic system in the 64-8/4 standard with a nominal voltage greater than U = 1.125 V (according to the voltmeter between the positive and negative poles in CEI HD 07 S361 4 Table 3 Insulation steps 3)
application
This cable does not meet Art’s double insulation requirements. CEI 412.2.4.1 b) Conduit of the DC portion of the photovoltaic system in the 64-8/4 standard with a nominal voltage greater than U = 1.125 V (according to the voltmeter between the positive and negative poles in CEI HD 07 S361 4 Table 3 Insulation steps 3)
peculiarity
- EN 50618 p.q.a.
- EN 60228 EN 50395
- EN 50618 p.p. q.a.
- EN 50618 p.q.a. EN 50395 EN 62230
- EN 50618 p..。 q.a. EN 50396 EN 60228
- EN 60811-401 EN 50618 p.q.a.
- EN 60811-504 EN 60811-505 EN 60811-506 EN 50618 p.q.a. EN 60811-403 EN 50396 EN 50618 p.q.a. EN 50618 p.q.a.
- EN 50289-4-17 Method A
- EN 50618 p.q.a.
- EN 60068-2-78
- EN 60811-503
- EN 60332-1-2
- EN 61034-2 （LT≥60%）
- 50525-1
- EN 50618 pqa. EN 60216-1 EN 60216-2
ADDITIONAL INFORMATION
/
Product structure
| conductor | Bare copper wire complies with IEC 60228, VDE 0295, class 5 standards |
|---|---|
| insulation | Cross-linked LSZH-free rubber (LSZH-XL) |
| color | white |
| structure | / |
| Wrap the bag | Polyester with cladding |
| shield | Galvanized steel wire braided armor |
| Sheath material: | Special Cross-linked LSZH Rubber (LSZH-XL+) |
| Sheath color | RAL 9005 Pure Black
RAL 3000 standard red |
Technical parameters
| Operating voltage | Core operating voltage
Rated Operating Voltage: 1.5kV DC (also to ground) Maximum Operating Voltage: 1.8kV DC (also to ground) Outer sheath working voltage Rated Operating Voltage: 1.5kV DC (also to ground) Maximum Operating Voltage: 1.8kV DC (also to ground) |
|---|---|
| Test voltage | 15kV DC |
| Temperature range | Minimum operating temperature -40°C long-term operation allowance
Maximum operating temperature +90°C long-term operation allowance Short-circuit withstand temperature +250°C for a duration of ≤5 seconds |
| environmental protection | Comply with EU RoHS directive |
Cable parameters
| numbering | specification | The finished outer diameter is -ø | Max. Resistance (20° C) | |
|---|---|---|---|---|
| LS2380205 | 2 x 0.35 mm² | 1.8X3.7 mm | 247.0 ohm/km | Send an inquiry |
| LS2380305 | 2 x 0.5 mm² | 2.1X4.2 mm | 39.0 ohm/km | Send an inquiry |
| LS2380405 | 2 x 0.75 mm² | 2.3X4.6 mm | 26.0 ohm/km | Send an inquiry |
| LS2380505 | 2 x 1.0 mm² | 2.4X4.8 mm | 19.5 ohm/km | Send an inquiry |
| LS2380705 | 2 x 1.5 mm² | 2.9X5.8 mm | 13.3 ohm/km | Send an inquiry |
| LS2381205 | 2 x 2.5 mm² | 3.3X6.6 mm | 7.98 ohm/km | Send an inquiry |
Other sizes and colors are available upon request. The above data is for reference only and is subject to the actual product. Other sizes and colors are available upon request. The above data is for reference only and is subject to the actual product.
