2YSLCYK-J MOTOR 3+3PE Dca 450/750 V
The cable complies with the requirements of the Construction Products Regulation (EU CPR 305/11) and is designed to limit the generation and spread of fire and smoke.
Due to its special construction, when full electromagnetic compatibility (EMC) is required, shielded cables are used to power motors with frequency converters.
The symmetrical cable structure (3 + 3PE) ensures the symmetry of the supply voltage on the motor terminals. Suitable for static and dynamic connections (occasional movement) in industrial plants, production lines and machinery operating in normal or humid environments.
Direct or indirect underground installation (presence of water condition AD7).
application
The cable complies with the requirements of the Construction Products Regulation (EU CPR 305/11) and is designed to limit the generation and spread of fire and smoke.
Due to its special construction, when full electromagnetic compatibility (EMC) is required, shielded cables are used to power motors with frequency converters.
The symmetrical cable structure (3 + 3PE) ensures the symmetry of the supply voltage on the motor terminals. Suitable for static and dynamic connections (occasional movement) in industrial plants, production lines and machinery operating in normal or humid environments.
Direct or indirect underground installation (presence of water condition AD7).
peculiarity
-
- IEC 60228
ADDITIONAL INFORMATION
- Custom core/jacket color
Product structure
| conductor | Class 5 Bare Copper Soft Conductors (IEC 60228 Class 5) |
|---|---|
| insulation | Polyethylene (PE) material |
| color | Brown x3 + black x3 + gray x3 + yellow and green bicolor x3 |
| structure | Concentric layer stranded conductors |
| Wrap the bag | Full-section polyester strap |
| shield | First shield:
Full-section aluminum-plastic composite belt Second shield: Full section tinned copper woven mesh |
| Sheath material: | Flame retardant PVC composite sheath |
| Sheath color | RAL 9005 |
Technical parameters
| Operating voltage | Core operating voltage 0.6/1 kV
The outer jacket operates at 1.8kV DC and 1.2kV AC |
|---|---|
| Test voltage | 4000V |
| Temperature range | Operating temperature range
▸ Fixed laying: -25°C ~ -5°C ▸ Non-stressed temporary mobile laying: +70°C ~ +70°C Short-circuit tolerance limit ▸ Maximum instantaneous temperature: +160°C (duration ≤5 seconds) |
| environmental protection | Comply with EU RoHS directive |
Cable parameters
| numbering | specification | The finished outer diameter is -ø | Max. Resistance (20° C) | |
|---|---|---|---|---|
| LS2380205 | 2 x 0.35 mm² | 1.8X3.7 mm | 247.0 ohm/km | Send an inquiry |
| LS2380305 | 2 x 0.5 mm² | 2.1X4.2 mm | 39.0 ohm/km | Send an inquiry |
| LS2380405 | 2 x 0.75 mm² | 2.3X4.6 mm | 26.0 ohm/km | Send an inquiry |
| LS2380505 | 2 x 1.0 mm² | 2.4X4.8 mm | 19.5 ohm/km | Send an inquiry |
| LS2380705 | 2 x 1.5 mm² | 2.9X5.8 mm | 13.3 ohm/km | Send an inquiry |
| LS2381205 | 2 x 2.5 mm² | 3.3X6.6 mm | 7.98 ohm/km | Send an inquiry |
Other sizes and colors are available upon request. The above data is for reference only and is subject to the actual product. Other sizes and colors are available upon request. The above data is for reference only and is subject to the actual product.
