ARG16M16 600/1000 V

application

It is suitable for general applications in construction projects with fire response requirements, as well as bundle installation occasions with high fire risk in situations such as high crowd density, difficulty in evacuating people for a long time, or possible significant damage to animals and plants. It is also recommended for use in places where there is a risk of explosion or fire, such as thermal power plants, power plants, chemical plants, petrochemical plants, steel plants, fuel facilities, etc.

Suitable for indoor and outdoor installations, including wet locations, fixed installations on masonry or metal structures, and also allow direct buried laying.

Certifications and standards

– CEI 20-13; – CEI EN/IEC 60228; – CEI EN/IEC 60332-1-2; – CEI EN 50575:2014+A1:2016; – CEI EN 50399;
Low Voltage DC 2006/95/EC,
According to CEI 64-8:V4 section 751.04.3a, this cable has a fire response rating of Cca-S1B,D1,A1. Among them, CCA indicates that its combustion performance grade is C grade, which is a moderate contribution; S1b indicates less smoke when burned; d1 indicates that certain combustion droplets or particles will be produced during the combustion process; A1 indicates that the cable does not produce acid gases.
ROHS DC 2002/95/EC certification

ADDITIONAL INFORMATION

Can be customized Core Count X1.5mm² + Core Count X 0.34mm²
For example: 4*1.5mm²+4X0.34mm²
Custom splices, wiring harnesses, etc

Product structure

conductor	Class 2 stranded aluminum wire in accordance with CEI EN/IEC 60228
insulation	G16 Quality High Modulus Ethylene Propylene Rubber (HEPR)
color	black
shield	not
Sheath material:	M16 quality thermoplastic mixture
Sheath color	Green (RAL 6026), other colours optional

Technical parameters

Nominal voltage	Uo/U = 600/1000 V c.a. / a.c
Test voltage	3000V
Bending radius	Fixed laying: 6xd
Flame retardant	IEC 60332.1
Temperature range	Fixed application: -15/+80°C Flexible application: +5/+70°C Large short circuit temperature: 250°C
Tensile resistance	5 Kg / mm²
environmental protection	Comply with EU RoHS directive

Cable parameters

numbering	specification	Insulation thickness	Outer diameter – ø	Cable weight ≈	Max. Resistance (20° C)
L02621007	10 mm²	0,7 mm	11.2 mm	95 kg/km	3.08 ohm/km	Send an inquiry
L02621507	16 mm²	0,7 mm	12.0 mm	120 kg/km	1.91 ohm/km	Send an inquiry
L02622507	25 mm²	0,9 mm	13.6 mm	175 kg/km	1.20 ohm/km	Send an inquiry
L02624007	35 mm²	0,9 mm	14.6 mm	210 kg/km	0.868 ohm/km	Send an inquiry
L02626007	50 mm²	1.0 mm	15.9 mm	265 kg/km	0.641 ohm/km	Send an inquiry
L02610007	70 mm²	1.1 mm	17.8 mm	340 kg/km	0.443 ohm/km	Send an inquiry
L02616007	95 mm²	1.1 mm	19.5 mm	440 kg/km	0.320 ohm/km	Send an inquiry
L02625007	120 mm²	1.2 mm	21.4 mm	540 kg/km	0.253 ohm/km	Send an inquiry
L02623507	150 mm²	1,4 mm	23.1 mm	650 kg/km	0.206 ohm/km	Send an inquiry
L02650000	185 mm²	1,6 mm	25.7 mm	795 kg/km	0.164 ohm/km	Send an inquiry
L02670000	240 mm²	1,7 mm	28.3 mm	1010 kg/km	0.125 ohm/km	Send an inquiry
L02695000	300 mm²	1,8 mm	31.2 mm	1223 kg/km	0.206 ohm/km	Send an inquiry
L02120000	400 mm²	2.0 mm	35.7 mm	1592 kg/km	0.100 0hm/km	Send an inquiry
L02150000	500 mm²	12.2 mm	39.3 mm	2046 kg/km	0.0778 ohm/km	Send an inquiry
L02185000	630 mm²	2.4 mm	43.6 mm	2508 kg/km	0.0469 ohm/km	Send an inquiry
