ARG16R16 600/1000 V

application

Special purpose power cables for use in traction vehicles (e.g. on trains, trams or subways) and buses as well as dry indoor environments. In switching boards and distribution cabinets rated for voltages up to 1000 volts, these cables are considered to have short-circuit and ground fault protection. They are also oil and flame resistant in single vertical cable tests. These cables are only used for power transmission and must be installed by professionals.

Certifications and standards

-CEI UNEL 35394; – CEI 20-13; – CEI EN/IEC 60228; – CEI EN/IEC 60332-1-2; – CEI EN 50575:2014+A1:2016; – CEI EN 50399;
Low Voltage DC 2006/95/EC,
ROHS DC 2002/95/EC certification

ADDITIONAL INFORMATION

Can be customized Core Count X1.5mm² + Core Count X 0.34mm²
For example: 4*1.5mm²+4X0.34mm²
Custom splices, wiring harnesses, etc

Product structure

conductor	Class 2 stranded aluminum wire in accordance with CEI EN/IEC 60228
insulation	G16 Quality High Modulus Ethylene Propylene Rubber (HEPR)
color	black
shield	not
Sheath material:	R16 type polyvinyl chloride
Sheath color	Grey (RAL 7001), other colours available

Technical parameters

Nominal voltage	Uo/U = 600/1000 V c.a. / a.c Uo/U = 900/1500 V c.c. / d.c. Um = 1200 V c.a. / a.c Um = 1800 V c.c. / d.c.
Test voltage	3000V
Bending radius	Fixed laying: 6xd
Flame retardant	IEC 60332.1
Temperature range	Fixed application: -15/+80°C Flexible application: +5/+70°C Large short circuit temperature: 250°C
Tensile resistance	5 Kg / mm²
environmental protection	Comply with EU RoHS directive

Cable parameters

numbering	specification	Insulation thickness	Outer diameter – ø	Cable weight ≈	Max. Resistance (20° C)
L02621007	10 mm²	0,7 mm	12.0 mm	135 kg/km	3.08 ohm/km	Send an inquiry
L02621507	16 mm²	0,7 mm	12.5 mm	143 kg/km	1.91 ohm/km	Send an inquiry
L02622507	25 mm²	0,9 mm	13.7 mm	192 kg/km	1.20 ohm/km	Send an inquiry
L02624007	35 mm²	0,9 mm	15.0 mm	231 kg/km	0.868 ohm/km	Send an inquiry
L02626007	50 mm²	1.0 mm	16.2 mm	282 kg/km	0.641 ohm/km	Send an inquiry
L02610007	70 mm²	1.1 mm	18.1 mm	362 kg/km	0.443 ohm/km	Send an inquiry
L02616007	95 mm²	1.1 mm	20.1 mm	458 kg/km	0.320 ohm/km	Send an inquiry
L02625007	120 mm²	1.2 mm	22.0 mm	555 kg/km	0.253 ohm/km	Send an inquiry
L02623507	150 mm²	1,4 mm	24.3 mm	5665 kg/km	0.206 ohm/km	Send an inquiry
L02650000	185 mm²	1,6 mm	26.7 mm	807 kg/km	0.164 ohm/km	Send an inquiry
L02670000	240 mm²	1,7 mm	29.6 mm	1012 kg/km	0.125 ohm/km	Send an inquiry
L02695000	300 mm²	1,8 mm	32.2 mm	1223 kg/km	0.206 ohm/km	Send an inquiry
L02120000	400 mm²	2.0 mm	36.7 mm	1592 kg/km	0.100 0hm/km	Send an inquiry
L02150000	500 mm²	12.2 mm	40.3 mm	2046 kg/km	0.0778 ohm/km	Send an inquiry
L02185000	630 mm²	2.4 mm	44.6 mm	2508 kg/km	0.0469 ohm/km	Send an inquiry
