H05Z-K Halogen-free LSOH insulation Class 5 conductors -30 ∽+90°C 300/500V
Suitable as an internal connection cable for equipment. As system wiring, it needs to be protected or laid in a casing. Halogen-free type, no toxic gas and thick smoke are produced when burned, protecting human safety.
CE= products comply with the EU Low Voltage Directive 2014/35/EU
application
Suitable as an internal connection cable for equipment. As system wiring, it needs to be protected or laid in a casing. Halogen-free type, no toxic gas and thick smoke are produced when burned, protecting human safety.
CE= products comply with the EU Low Voltage Directive 2014/35/EU
peculiarity
- Halogen-free, flame-retardant and self-extinguishing
Product structure
| conductor | Multi-strand conductors. Compliant with IEC 60228, VDE 0295, Level 1 (tinned conductors can be customized on request) |
|---|---|
| insulation | Halogen-free special polymers |
| Color code | See table* |
Supplementary information
*The color code of the single wire/core wire can be selected as follows:
| Color code | color | Color code | color |
| 01 = | black | 06 = | green |
| 02 = | blue | 07 = | purple |
| 03 = | brown | 08 = | white |
| 04 = | grey | 16 = | Blue |
| 05 = | Yellow | 27 = | Green/yellow |
Single-core/clue color code
Technical parameters
| Nominal voltage | Ibid./U 300/500V |
|---|---|
| Test voltage | 2000 V |
| Bending radius/min | 15XD
One corner: 10xD |
| Temperature range | Fixed laying: -40/+90 °C
Flexible application: -5/+90 °C Temperature reachable in case of short circuit: +250º C |
| Halogen-free | Compliant with IEC 60754-1 + VDE 0482-754-1 |
| Fire resistance | Flame retardant and self-extinguishing compliant. Complies with IEC 60332-1-2 + VDE 0482-332-1-2 |
| Corrosiveness of combustion gases | Compliant with IEC 60754-2 + VDE 0482-754-2 – No corrosive combustion gases are generated |
| Smoke density | Compliant with IEC 61034 + VDE 0482-1034 |
| flexibility | Good |
| environmental protection | Comply with EU RoHS directive |
Cable parameters
| numbering | specification | Copper weight | Finished product weight | |
|---|---|---|---|---|
| K7100 .. 25* | 0.5 mm² | 4.8 kg/km | 8 kg/km | Send an inquiry |
| K7100 .. 34* | 0.75 mm² | 7.2 kg/km | 12 kg/km | Send an inquiry |
| K7100 .. 50* | 1.0 mm² | 9.6 kg/km | 14 kg/km | Send an inquiry |
Other sizes and colors can be upon request. The above data is for reference and subject to reality.
