MTC 303
Mineral insulated thermocouple with Lemo connection element
Application
Mineral insulated thermocouple type K (NiCr-Ni), nominal lengths available. The measuring head type can be selected as Type 1 Type A or Type 1 Type B. Thermocouples can also be constructed as 2 x K type.
Construction
| Thermocouple |
The following thermocouple types can be selected depending on the application: 1 x L Type – 2 x type L 1 x J Type – 2 x type J 1 x type K – 2 x type K – Other thermocouples – on customer request Type L to DIN 43710 Types J and K to DIN EN 60584 |
|---|---|
| Sheath diameter |
0,64 mm 1,0 mm 1.5 mm 2,0 mm 3,0 mm 4.5 mm 6,0mm – Other sheath diameters – on customer request |
| Sheath material |
– 1.4541 – 2.4816 – Other sheath materials – on customer request |
| Connecting element |
– Socket size 0 – Plug size 0 – Socket size 1 – Plug size 1 – Socket size 2 – Plug size 2 – Other connecting elements – on customer request |
| Accessories (fixed) |
– without socket/plug housing – with socket/plug housing – Special accessories – on customer request |
| Measuring tip type |
– Class 1, type A – Class 1, Table B |
| Nominal length |
According to customer requirements. Please specify (in mm) |
Technical data
Dimensions
